Forged Steel Valve

FORGED STEEL Valve

‘FLOWON’ Forged Steel Valves has created a dominance in the market due to its best-in-class Quality, On time Delivery, Service and most affordable Price range. Our Forged Steel Valves are made from high quality forgings which are procured from our renowned vendors. All the internal parts used in valves are manufactured using high quality CNC machine. ‘FLOWON’ Forged Valves are manufactured, Assembled and Tested as per the applicable industrial standards like ASME, ANSI, API etc. Testing of valve is done on automatic testing machine which tests 10 valves at a time thus increasing productivity and reduce time. The Forging of all valves are Chemically and Mechanically tested at the time of material reception to ensure the quality of valves.

Forged Steel Valve manufactured by ‘FLOWON’ is

forged gate valve
GATE VALVE
forged globe valve
GLOBE VALVE
forged check valve
CHECK VALVE
forged gate valve

GATE VALVE

‘FLOWON’ forged type OS & Y type rising stem, non-rising handwheel Gate Valve are manufactured using high quality Body and Bonnet forgings which has integral backseat. Depending upon pressure class, two types of Body-Bonnet Joint design are available. Bolted Bonnet are generally used for 800# and for 1500# and 2500#, Welded bonnet is used to ensure tight sealing of Body-Bonnet area. Wedge and Seat ring used in Gate Valve is made of forged round bar. Gland and flange is of two-piece design which allows the flange to be evenly tightened and to remain parallel to the stem and packings.

PRODUCT RANGE
Size Pressure Rating
1/2" to 2.5"
800#
1/2" to 2"
1500#
1/2" to 1.5"
2500#
1/2" to 2.5"
150#,300#

MATERIAL

A105 / A105N, F-304/304L, F-316/316L,
F-11, F-22, F-51, F-91

END CONNECTION

½” to 2.5”, ½” to 2 and ½” to 1.5”
Screwed, Socket end
½” to 2.5”
Flanged End

TECHNICAL SPECIFICATIONS
  • Design Standards: API 602
  • Testing Standards: API 598
forged globe valve

GLOBE VALVE

‘FLOWON’ forged type OS & Y type Globe Valve are manufactured using high quality Body and Bonnet forgings which has integral backseat. Depending upon pressure class, two types of Body-Bonnet Joint design are available. Bolted Bonnet are generally used for 800# and for 1500# and 2500#, Welded bonnet is used to ensure tight sealing of Body-Bonnet area. Disc and seat ring used in Globe Valve is made of forged round bar. Gland and flange is of two-piece design which allows the flange to be evenly tightened and to remain parallel to the stem and packings.

PRODUCT RANGE
Size Pressure Rating
1/2" to 2.5"
800#
1/2" to 2"
1500#
1/2" to 1.5"
2500#
1/2" to 2.5"
150#,300#

MATERIAL

A105 / A105N, F-304/304L, F-316/316L,
F-11, F-22, F-51, F-91

END CONNECTION

½” to 2.5”, ½” to 2 and ½” to 1.5”
Screwed, Socket end
½” to 2.5”
Flanged End

TECHNICAL SPECIFICATIONS
  • Design Standards: BS 5352
  • Testing Standards: API 598
forged check valve

CHECK VALVE

‘FLOWON’ forged Lift type Check Valve are manufactured using high quality Body and Cover forgings as per BS Standards. Heavy duty piston guided by spring is used internally for one way flow of fluid. Bolted Bonnet are generally used for 800# and for 1500# and 2500#, Welded bonnet is used to ensure tight sealing of Body-Cover area.  Spiral Wound gasket is used for tight sealing of Body-Cover joint.

PRODUCT RANGE
Size Pressure Rating
1/2" to 2.5"
800#
1/2" to 2"
1500#
1/2" to 1.5"
2500#
1/2" to 2.5"
150#,300#

MATERIAL

A105 / A105N, F-304/304L, F-316/316L,
F-11, F-22, F-51, F-91

TECHNICAL SPECIFICATIONS
  • Design Standards:  BS 5352
  • Testing Standards: BS 6755
